Answer: DEL-F10-F1-DEL-DEL-DEL-F8-F10-F8-F1-DEL-F10-F12-DEL-DEL-F11.
In that sequence, to be completed within 3 seconds.

BIOS

Do you prefer UEFI? Really??
Anyway, racadm, ipmitool, some stuff are probably common to BIOS and UEFI ;-)

Penguin Computing

F2 = Setup
F10 = Display Boot Menu
F12 = Force Network Boot

For BMC/IPMI was said to default to share eth0 with host os when service RJ45 isn't connected.
However, my systems wasn't setup that way.
To make IPMI share eth0 with the host os, set it with:
ipmitool raw 0x2e 0xcc 0x5e 0x2b 0 0x0C 0x01 0x02

Note that ipmi already have a default admin/admin account as user 2.
If setting new admin acc, try to rename the existing one first:
ipmitool user set name 2 oper
ipmitool user list 1

Lenovo Server

F1 		Setup
F2		Diagnostics
F12		Select Boot Device	# Need legacy mode to do PXE boot

Lenovo Desktop/Laptop

Enter  (or ThinkVantage button)

SuperMicro

During Post, keys:

tab		Display BIOS POST message

del		run setup (BIOS)
F2 		run setup (BIOS)
F11		boot menu
F12		Network boot


RAID controller
AVAGO MegaRAID SAS-MFI BIOS  v5.50.03.0  July 2015)

^P		pause		(disk scanning?)
^V		skip

^H 		WebBIOS
^Y		preboot CLI

Tyan

del or F2		run setup (AMI BIOS)
F12 boot from ...

Asus

del		run setup (AMI BIOS)
alt+F2 - EzFlash
F8 = BBS POPUP # ie boot device menu


^B PXE prompt for Intel I350 on-board NIC

Dell

PowerEdge
F2  = System Setup
F10 = Lifecycle Controller (BIOS setup)
F11 = Boot Manager
F12 = PXE boot

^A = Avago raid controller

HT - Hyperthreading/Logical Processor

/opt/dell/srvadmin/sbin/racadm get BIOS.ProcSettings.LogicalProc		# query HT status

/opt/dell/srvadmin/sbin/racadm set BIOS.ProcSettings.LogicalProc Disabled	# disable HT
/opt/dell/srvadmin/sbin/racadm jobqueue create BIOS.Setup.1-1			# create job to change BIOS setting
/opt/dell/srvadmin/sbin/racadm serveraction powercycle				# power cycle to effect change

SNC - Sub NUMA Cluster on Skylake

Leave SNC disabled (default).
See Fig 2 of: http://en.community.dell.com/techcenter/high-performance-computing/b/general_hpc/archive/2017/08/01/bios-characterization-for-hpc-with-intel-skylake-processor
Skylake... 14th gen PowerEdge...
"introduce a clustering mode called Sub NUMA clustering (SNC). On CPU models that support SNC, enabling SNC is akin to splitting the single socket into two NUMA domains, each with half the physical cores and half the memory of the socket."

Query Sub NUMA Cluster (SNC) modes
	- numactl -H
	- /opt/dell/srvadmin/sbin/racadm get BIOS.ProcSettings.SubNumaCluster
	- lstopo

- SNC=Disabled (default).  ie, two socket show up as two NUMA domains.
- SNC=Enabled.  within socket has split NUMA domains. two socket system would then have FOUR NUMA domains.  application who does not optimize for memory locality would be worse off.  Thus, not recommended unless benchmark and tuning has been done that benefit from this setting.

SNC disabled is baseline.  If enable SNC:
- STREAM, WRF, Fluent, which are highly localized memory optimized, have slight gain of 1-2%
- HPL was ~1% worse off.

	- /opt/dell/srvadmin/sbin/racadm get BIOS.MemSettings.NodeInterleave

- Disabled (default) = system support NUMA (asymmetric) mem config
- Enabled = memory interleave is supported IF symetric memory config is installed.  (SNC will not work when memory configured this way?)

See racadmSetBios.sh script that set this and many below values.

Numa on Epyc Rome 7xx2


BIOS.ProcSettings.NumaNodesPerSocket # default to 4, and numactl -H will show node with 0 RAM :/
BIOS.ProcSettings.ProcVirtualization

Memory Operating Mode

racadm help BIOS.MemSettings.MemOpMode
	OptimizerMode - Optimizer Mode (default)
	SingleRankSpareMode - Single Rank Spare Mode;
	MirrorMode - Mirror Mode;
	FaultResilientMode - Fault Resilient Mode;

	OppSrefEn=Disabled (default)

DAPC & GFLOPS/watt

DAPC profile consume less power than Performance profile, yet said to produce essentially same chrunching power. [my actual HPL test lost 7% performance]
See Fig 3 + 4 of: http://en.community.dell.com/techcenter/high-performance-computing/b/general_hpc/archive/2017/08/01/bios-characterization-for-hpc-with-intel-skylake-processor
Skylake... 14th gen PowerEdge...
- In idle state, Performance Profile consumes ~28% more power than DAPC.
- Peak power consumption in DAPC Profile is ~16% less than in Performance Profile.
- STREAM, WRF have essentialy same performance in either Performance or DAPC mode.
- HPL is 1.05% better in Performance than DAPC mode.
- Fluent is ~1.01% better.

/opt/dell/srvadmin/sbin/racadm get BIOS.SysProfileSettings.SysProfile
	SysProfile=PerfOptimized	(default)

/opt/dell/srvadmin/sbin/racadm set BIOS.SysProfileSettings.SysProfile PerfPerWattOptimizedOs

	Using PerfPerWattOptimizedDapc:
	- TBA

	Using PerfPerWattOptimizedOs:
	- Reduce HPL performance by ~7% on Skylake 6130 2.1 GHz 32cores 96G on Dell C6420
	- Exposes HPL clock calculation bug in random manner (cuz it messes with CPU clock?)

  Using LowLatencyOptimizedProfile:
	- This was undocumented profile in 12th Gen PowerEdge
	- said to make a world of difference for latency , but has significant draw on power and will keep all fans blowing on full speed all the time

racadm help BIOS.SysProfileSettings.SysProfile  # list available modes (and dependencies):
	- PerfPerWattOptimizedDapc - Performance Per Watt (DAPC)
	- PerfPerWattOptimizedOs - Performance Per Watt (OS)
	- PerfOptimized - Performance
	- PerfWorkStationOptimized - Workstation Performance;Custom - Custom;

Other BIOS param

When CPU doesn't perform, check these params (racadm):
  set BIOS.ProcSettings.LogicalProc      Disabled       # non default, but HPC don't want HT on
  set BIOS.MemSettings.MemOpMode         OptimizerMode	# default, should not need to change this for HPC
  set BIOS.MemSettings.NodeInterleave    Enabled	# non default, not compatible with SubNumaCluster, not typically recommended
  set BIOS.ProcSettings.SubNumaCluster   Enabled	# non default, only useful if app can better utlize localized mem
  set BIOS.SysProfileSettings.SysProfile PerfOptimized	# default
  set BIOS.SysProfileSettings.SysProfile PerfPerWattOptimizedDapc	# said to save energy
  set BIOS.SysProfileSettings.SysProfile PerfPerWattOptimizedOs		# may save energy, seems to introduce clock/timing bug
  set BIOS.ProcSettings.ControlledTurbo  Enabled 	# allow for external control of when to engage turbo?  Def: Disabled.
  get BIOS.ProcSettings.ProcTurboMode			# def Enabled, changeable only in Custom SysProfile
  get BIOS.SysInformation.SystemBiosVersion             # BIOS version

  set BIOS.SysProfileSettings.SysProfile Custom		# need custom mode to set the next two option:
  set BIOS.SysProfileSettings.ProcCStates Autonomous 	# def: Disabled. alt: Enabled # to allow proc to operate in all avail power state
  set BIOS.SysProfileSettings.UncoreFrequency DynamicUFS	# def: MaxUFS
      # https://software.intel.com/en-us/forums/software-tuning-performance-optimization-platform-monitoring/topic/543513

  # Perhaps also check:

  get BIOS.ProcSettings.UpiPrefetch			# def: Enabled
  get BIOS.MemSettings.OppSrefEn			# def: Disabled
  get BIOS.SysProfileSettings.MemFrequency		# def: MaxPerf.  Could choose diff speed such as 2666 MHz, 2400, 1866.
  get BIOS.SysProfileSettings.ProcC1E			# def: Disabled  # but enabled when switch to Custom SysProfile !!
							# Enable = processor is allowed to switch to minimum performance state when idle.
  get BIOS.SysProfileSettings.EnergyPerformanceBias	# def: MaxPower (ie Performance).
							# alt: BalancedPerformance, BalancedEfficiency, LowPower
Undocumented HPL parameter
# set env var for HPL to properly use AVX
export HPL_HOST_ARCH=3 # AVX2,  eg Hashwell
export HPL_HOST_ARCH=9 # AVX512 eg Skylake

KNL BIOS settings

KNL specific cpu/memory config:
racadm help BIOS.MemSettings...
MemThrottlingMode
	Cltt  (def)
	Oltt

SystemMemoryModel
	All2All
	SNC-2
	SNC-4
	Hemisphere
	Quadrant (def)	# 2x2

ProcEmbMemMode		# KNL Memory Mode.  affect "free -h", "numactl -H"
	Cache (def)
	Memory		# ie flat mode, memory seen in "free -h" and malloc-able.
	Hybrid
BIOS.ProcSettings
DynamicCoreAllocation=Disabled 	-- This field enables or disables the OS capability to put logical processors in the idling state in order to reduce power consumption.
ProcConfigTdp=Nominal 		-- This field allows reconfiguration of TDP (Thermal Design Power) to lower levels.

Retrieve Serial stored in BIOS

  racadm  get System.ChassisInfo	# service tag of chassis, eg Dell C6420 chassis
  racadm  get System...			# service tag of blade/sledge


  ipmitool fru | grep Serial   						# list all fru and filter for serial of sledge/blade
  ipmitool raw 0x30 0xc8 0x01 0x00 0x0b 0x00 0x00 0x00 | xxd -r 	# get Dell C6320 chassis service tag vintage 2017
More info, eg fetching Dell C6220 II chassis serial, see: ipmi

Misc

racadm techsupreport collect 	# start a support collection
racadm jobqueue view
racadm techsupreport export -f tsr_report.zip         # didn't work via singularity img (cuz idrac version diff?)
racadm supportassist exportlastcollection -f tsr.zip  # via sl7-tools vnfs

racadm racreset		# restart rac, like power cycling the service processor, but not the wipe config and restore to factory default kind of reset, which does have a separate cmd for

ipmi
Dell maintain their own version of ipmi that handles complex situation that RHEL7 ipmitool didn't. eg:
./ipmitool delloem lan set shared with lom1
racadm set iDRAC.NIC.Selection 2

with the selections as follows
1 - Dedicated
2 - LOM1
3 - LOM2
4 - LOM3
5 - LOM4

Ref
Intel E5 v3 (Hashwell) bios param tuning for Fabric(Omnipath, Infiniband).

Dell Ref

Ref:

SuperMicro (bios) update manager

SUM = supermicro update manager, not the checksum command from the OS!

  • simple binary to extract out of tgz file, then it just run.
  • write to current dir for a sum.log file.
  • root access required
  • Note that older bios output is simple key-value pair flat file, whereas newer bios is in XML format. (it has nothing to do with SUM version (eg 2.0 vs 2.2, older version with newer bios still produce XML output).

    untar gz, no real need to install
    ./sum -h				# not the checksum command in linux default path...





    sum -i 10.10.... -u ADMIN -p ADMIN -c GetBIOSInfo	# use IPMI interface to get info
    sum -c GetBIOSInfo			# this find out firmware version info, etc.  run on local machine
    sum -c UpdateBios --file BIOS.rom 	# this update bios, not change config

    sum -c GetCurrentBiosCfg  --file  smBiosCf.txt	# write output of BIOS settings (HT on or off, etc) to file
    sum -c GetCurrentBiosCfg     >    smBiosCf.txt	# should be same, but couple of places have * (default) next to diff entries.  also has SM(c) header, should avoid

    vi smBiosCf.txt		# make desired changes to BIOS use hex code for values. eg turn off Hyperthreading
    			# remove the first two lines of cfg that had the SM copyright info
    			# in KNL, file was simple text file
    			# in skylake, file was xml (UEFI bios?)

    sum -c ChangeBiosCfg --file smBiosCf.txt --reboot	# update bios config, rebooting host
    							# --reboot would actually be an soft reboot telling OS to shutdown (via ACPI?)

    sum -h -c ChangeBiosCfg				# get help on how to make changes to bios

    sum -c LoadDefaultBiosCfg
    sum -c GetDmiInfo


    Select GetCurrentBiosCfg entries
    sum -c GetCurrentBiosCfg | egrep --color 'Hyper-Threading|Turbo|CPU\ C\ State=|Cluster\ Mode=|Memory\ Mode='

    [Advanced|Boot Feature]
    Quiet Boot=01                           // Please enter the value in 2 hexadecimal digits. Default value is <<<01>>>

    [Advanced|Processor Configuration]
    Intel(R) Hyper-Threading Technology=01  // 01 (Disable), *00 (Enable)

    [Advanced|Processor Configuration|Advanced Power Management Configuration|CPU P State Control]
    Energy efficient P-state=01             // 00 (Disable), *01 (Enable)
    Turbo Mode=01                           // 00 (Disable), *01 (Enable)

    [Advanced|Processor Configuration|Advanced Power Management Configuration|CPU C State Control]
    CPU C State=01                          // 00 (Disable), *01 (Enable)


    [Advanced|Chipset Configuration|North Bridge|Uncore Configuration]
    Cluster Mode=00                         // *00 (All2All), 01 (SNC-2), 02 (SNC-4), 03 (Hemisphere), 04 (Quadrant), 05 (Auto)
    Memory Mode=01                          // *01 (Flat), 00 (Cache), 02 (Hybrid), 03 (Auto)
    MCDRAM Cache Size=02                    // 01 (25% of MCDRAM size), *02 (50% of MCDRAM size)        Memory Mode = "Flat" or Memory Mode = "Cache" or Memory Mode = "Hybrid" and Memory Mode = "Cache" or Memory Mode = "Hybrid" or Memory Mode = "Auto" and Memory Mode = "Flat" or Memory Mode = "Hybrid" or Memory Mode = "Auto"
    Treat MCDRAM as Hot-Pluggable Memory=00 // *00 (no), 01 (yes)        Memory Mode = "Flat" or Memory Mode = "Cache" or Memory Mode = "Hybrid" and Memory Mode = "Flat" or Memory Mode = "Hybrid" or Memory Mode = "Auto"
    OPIO Parallel Training=01               // *01 (Enable), 00 (Disable)
    OPIO Parallel Training Channel Count=08 // Please enter the value in 2 hexadecimal digits. Default value is <<<08>>>        OPIO Parallel Training = "Enable"
    MCDRAM Repair=01                        // 00 (Disable), *01 (Enable)
    MCDRAM Diagnostics=01                   // 00 (Disable), *01 (Enable)        MCDRAM Repair = "Disable"
    MCDRAM Data in NVRAM=01                 // 00 (Disable), *01 (Store), 02 (Use), 03 (UseStore)
    EDC Demand Scrub=01                     // *01 (Enable), 00 (Disable)
    EDC Patrol Scrub=01                     // 00 (Disable), *01 (Enable)


    [Advanced|Serial Port Console Redirection|COM1 Console Redirection Settings]
    Terminal Type=01                        // 00 (VT100), *01 (VT100+), 02 (VT-UTF8), 03 (ANSI)
    Bits per second=07                      // 03 (9600), 04 (19200), 05 (38400), 06 (57600), *07 (115200)
    Data Bits=08                            // 07 (7), *08 (8)
    Parity=01                               // *01 (None), 02 (Even), 03 (Odd), 04 (Mark), 05 (Space)
    Stop Bits=01                            // *01 (1), 03 (2)
    Flow Control=00                         // *00 (None), 01 (Hardware RTS/CTS)
    Legacy OS Redirection Resolution=01     // 00 (80x24), *01 (80x25)
    Putty KeyPad=01                         // *01 (VT100), 02 (LINUX), 04 (XTERMR6), 08 (SCO), 10 (ESCN), 20 (VT400)
    Redirection After BIOS POST=00          // *00 (Always Enable), 01 (BootLoader)


    SMC IPMI
    Info from serverfault

    Supermicro has an IPMICFG util that allows for custom commands like below. Get tool from: ftp Google Drive ver 1.31.1

    To change vlan tagging:
    ./IPMICFG-Linux.x86_64  -vlan off

    To reset the service processor:
    run ipmicfg -fde to reset all settings back to factory default,
    then ipmicfg -r to do a BMC cold reset
    after reset,  ipmicfg -m to see what’s IP, try ping it.

    To change which interface is used for IPMI:
    sudo ipmiutil lan -e										# check config
    sudo ipmiutil smcoem lanport dedicated  # set to shared

    instead of getting the util, can apparently just use raw commands via ipmitool. worked in 2020 on a server w/ cascade lake processor.

    It is slightly unerving not knowing what it is really doing and if it would work on a server of a different vintage... hopefully it can't do lasting damage.
    It didn't look like SUM was able to change the IPMI interface settings.

    To get LAN mode:                ipmitool raw 0x30 0x70 0x0c 0
    		output (entry for [B] for set):
    		0x00 = Dedicated,
    		0x01 = Onboard / Shared
    		0x02 = Failover
    		[A] = 0  is get
    		[A] = 1  is set
    .                                                           A B
    To set LAN mode dedicated:      ipmitool raw 0x30 0x70 0x0c 1 0
    To set LAN mode onboard/shared: ipmitool raw 0x30 0x70 0x0c 1 1
    To set LAN mode failover:       ipmitool raw 0x30 0x70 0x0c 1 2        # this seems like default; this settings worked as "shared"



    some say hard reboot needed, other says work right away without reboot.
    Apparently default depends whether were is live rj45 connected to the dedicated ipmi port when power was connected to computer.  So some changes may need power disconnect for it to take effect?



    Additional SMC IPMI raw commands in their support faq 15868. It is from 2003, and both X8 and X9, AMI or ATEN BIOS, seems to take the same set of commands.
    Asus IPMI raw


    For Asus ESC4000 G4 series (Skylake/Cascadelake, maybe Epyc Naples/Rome 7xx2 series as well).
    As with all raw commands, use at your own risk! :-D

    ipmitool lan set 8 cipher_privs XaaaaaaaaaaaXXX   # reset cipher suite allowed for channel 8

    # toggle on/off among the diff settings/interfaces should revive ipmi over lan

    # For Asus ESC4000 G4
    ipmitool raw 0x32 0x71 0x00 0x01 0x01 	# set ipmi/bmc to use shared nic
    # For Asus ASMB7-iKVM (P9D-MV)
    ipmitool raw 0x32 0x71 0x00 0x01 0x03		#    activate ipmi/bmc  on lan1 (shared with host/os nic)
    ipmitool raw 0x32 0x71 0x00 0x01 0x00		# de-activate ipmi/bmc  on lan1 (shared with host/os nic)
    ipmitool raw 0x32 0x71 0x00 0x00 0x03	  #    activate ipmi/bmc  on dm_lan1 (dedicated management port)
    ipmitool raw 0x32 0x71 0x00 0x00 0x00   # de-activate ipmi/bmc  on dm_lan1 (dedicated management port)

    ref: https://www.thomas-krenn.com/de/wiki/IPMI_Netzwerkports_von_ASUS_Mainboards_konfigurieren



    Service Processor

    ??

    tool to manipulate BIOS using cli tool... TBA

    Dell Support Assist


    singularity exec -B /var/run  /global/scratch/tin/singularity-repo/dirac1_dell_idracadm.img  \
    /opt/dell/srvadmin/sbin/racadm  supportassist collect

    Job ID = JID_926261291256
    RAC1154: The requested operation is initiated.

    Run the RACADM jobqueue sub-command, using the job id to check the status of
    the requested operation.


    racadm  jobqueue view
    -------------------------JOB QUEUE------------------------
    [Job ID=JID_926261291256]
    Job Name=SupportAssist Collection
    Status=Completed
    Start Time=[Not Applicable]
    Expiration Time=[Not Applicable]
    Message=[SRV088: The SupportAssist Collection Operation is completed successfully.]
    Percent Complete=[100]
    ----------------------------------------------------------



    	# this didn't work, not sure where file went:
      /global/scratch/tin/singularity-repo/dirac1_dell_idracadm.img  /opt/dell/srvadmin/sbin/racadm  supportassist  exportlastcollection -f tsr.zip

    # ftp server??!!
      racadm supportassist exportlastcollection -l ftp://192.168.10.24/share -u myuser -p mypass






    Lenovo DSA

    Lenovo Dynamic System Analyst (DSA).
    Collect system state/log for support to review. Portable version for rhel7 worked for vNFS n0096.s2
    Download ( https://support.lenovo.com/us/en/downloads/ds121924 ) self extracting elf .bin and right away run the program. don't seems to leave any binary behind when finsih. When finished, leave collected log in /var/log/Lenovo_Support Probably same thing that is invoked by "bios" collect tool, which save result to usb.
    Preliminary okay to give sudo to intern to run... keep a stable binary version in a non-writable place...
    wget https://download.lenovo.com/servers/mig/2017/05/17/6836/lnvgy_utl_dsa_dsala7d-10.3_portable_rhel7_x86-64.bi
    sudo ./lnvgy_utl_dsa_dsala7d-10.3_portable_rhel7_x86-64.bin






    Copyright info about this work

    This work is licensed under a Creative Commons Attribution-NonCommercial-ShareAlike2.5 License. Pocket Sys Admin Survival Guide: for content that I wrote, (CC) some rights reserved. 2005,2012 Tin Ho [ tin6150 (at) gmail.com ]
    Some contents are "cached" here for easy reference. Sources include man pages, vendor documents, online references, discussion groups, etc. Copyright of those are obviously those of the vendor and original authors. I am merely caching them here for quick reference and avoid broken URL problems.



    Where is PSG hosted these days?
